Retrieve Data from RESTFul API and add Paging in knockout.js

Retrieve Data from RESTFul API and add Paging in knockout.js

Ashutosh Kumar Verma 229 31-May-2024

Add knockout.js in HTML

To add Knockout.js to an HTML file, you need to include the Knockout.js library in your HTML document.

Example:

<!DOCTYPE html>
<html lang="en">
<head>
   <meta charset="UTF-8">
   <meta name="viewport" content="width=device-width, initial-scale=1.0">
   <title>Knockout.js Example</title>
   <!-- Include Knockout.js library -->
   <script src="https://cdnjs.cloudflare.com/ajax/libs/knockout/3.5.2/knockout-min.js"></script>
</head>
<body>
<!-- Your HTML content here -->
<script>
   // Your Knockout.js code here
</script>
</body>
</html>

Make sure to replace "https://cdnjs.cloudflare.com/ajax/libs/knockout/3.5.2/knockout-min.js" with the appropriate URL if you are hosting the library yourself or if you are using a different version.

Retrieve Data from RESTful API using knockout.js AJAX

//add jQuery CDN for using AJAX for retrieve data from API <script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/3.7.1/jquery.min.js"></script>
// Function to fetch data for the current page
self.fetchData = function () {
    $.ajax({
        url: self.DataUrl(),
        method: "GET",
        dataType: "json",
        success: function (response) {
            self.Data(response); // Populate allData array with fetched data
        },
        error: function (error) {
            console.log("error: ", error);
        }
    });
};

// Initially fetch all data
self.fetchData();

HTML Code for bind API data

<div class="row row-cols-1 row-cols-md-3 g-4" data-bind="foreach: currentPageData">
    <div class="col">
        <div class="card h-100">
            <div class="card-header">
                <span data-bind="text: id"></span>
            </div>
            <div class="card-body">
                <a class="text-decoration-none" data-bind="attr: {href: $root.DataUrl()+'/' +id}">
                    <p class="card-title fs-5 fw-semibold" data-bind="text: title"></p>
                </a>
                <p class="card-text" data-bind="text: body"></p>
            </div>
        </div>
    </div>
</div>

knockout.js code for adding Paging

self.currentPage = ko.observable(1);
self.itemsPerPage = ko.observable(10);
// Bind the data to the current page
self.currentPageData = ko.observableArray([]);

// Calculate total pages based on total items and items per page
self.totalPages = ko.observable();

// Function to navigate to the previous page
self.goToPreviousPage = function () {
    if (self.currentPage() > 1) {
        self.currentPage(self.currentPage() - 1);
    }
};

// Function to navigate to the next page
self.goToNextPage = function () {
    if (self.currentPage() < self.totalPages()) {
        self.currentPage(self.currentPage() + 1);
    }
};

// Function to navigate to a specific page
self.goToPage = function (pageNumber) {
    self.currentPage(pageNumber);
};

// Watch for changes in currentPage and fetch data accordingly
self.currentPage.subscribe(function () {
    var startIndex = (self.currentPage() - 1) * self.itemsPerPage();
    var endIndex = startIndex + self.itemsPerPage();
    self.currentPageData(self.Data().slice(startIndex, endIndex));
});self.currentPage.subscribe(function () { var startIndex = (self.currentPage() - 1) * self.itemsPerPage(); var endIndex = startIndex + self.itemsPerPage(); self.currentPageData(self.Data().slice(startIndex, endIndex)); });

HTML Code for add paging on the webpage

<!-- Pagination controls -->
<nav aria-label="Page navigation">
    <ul class="pagination justify-content-end mt-4">
        <li class="page-item" data-bind="css: {disabled: currentPage() === 1}">
            <a class="page-link" href="#" aria-label="Previous" data-bind="click: goToPreviousPage">
                <span aria-hidden="true">Prev</span>
            </a>
        </li>
        <!-- ko foreach: Array(totalPages()) -->
        <li class="page-item" data-bind="css: {active: $parent.currentPage() === ($index() + 1)}">
            <a class="page-link" href="#" data-bind="text: $index() + 1, click: function() { $parent.goToPage($index() + 1); }"></a>
        </li>
        <!-- /ko -->
        <li class="page-item" data-bind="css: {disabled: currentPage() === totalPages()}">
            <a class="page-link" href="#" aria-label="Next" data-bind="click: goToNextPage">
                <span aria-hidden="true">Next</span>
            </a>
        </li>
    </ul>
</nav>

Finally, bind all the knockout.js code to the webpage using the below code

$(document).ready(function () {
	ko.applyBindings(new AppViewModel());
});

Here is the complete code of the above samples

HTML Code

<!DOCTYPE html>
<html lang="en">

<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet">
    <script src="https://cdnjs.cloudflare.com/ajax/libs/knockout/3.5.1/knockout-latest.min.js"></script>
    <title>Fetch data from RESTful API</title>
</head>

<body>
    <div class="container my-4">
        <div class="row">
            <div class="col-12">
                <div class="row row-cols-1 row-cols-md-3 g-4" data-bind="foreach: currentPageData">
                    <div class="col">
                        <div class="card h-100">
                            <div class="card-header">
                                <span data-bind="text: id"></span>
                            </div>
                            <div class="card-body">
                                <a class="text-decoration-none" data-bind="attr: {href: $root.DataUrl()+'/' +id}">
                                    <p class="card-title fs-5 fw-semibold" data-bind="text: title"></p>
                                </a>
                                <p class="card-text" data-bind="text: body"></p>
                            </div>
                        </div>
                    </div>
                </div>

                <!-- Pagination controls -->
                <nav aria-label="Page navigation">
                    <ul class="pagination justify-content-end mt-4">
                        <li class="page-item" data-bind="css: {disabled: currentPage() === 1}">
                            <a class="page-link" href="#" aria-label="Previous" data-bind="click: goToPreviousPage">
                                <span aria-hidden="true">Prev</span>
                            </a>
                        </li>
                        <!-- ko foreach: Array(totalPages()) -->
                        <li class="page-item" data-bind="css: {active: $parent.currentPage() === ($index() + 1)}">
                            <a class="page-link" href="#"
                                data-bind="text: $index() + 1, click: function() { $parent.goToPage($index() + 1); }"></a>
                        </li>
                        <!-- /ko -->
                        <li class="page-item" data-bind="css: {disabled: currentPage() === totalPages()}">
                            <a class="page-link" href="#" aria-label="Next" data-bind="click: goToNextPage">
                                <span aria-hidden="true">Next</span>
                            </a>
                        </li>
                    </ul>
                </nav>
            </div>
        </div>
    </div>
   </body>
</html>

Js Code:

    <script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/3.7.1/jquery.min.js"></script>
    <script>
        function AppViewModel() {
            var self = this;

            self.DataUrl = ko.observable("https://jsonplaceholder.typicode.com/posts");
            self.Data = ko.observableArray([]);
            self.currentPage = ko.observable(1);
            self.itemsPerPage = ko.observable(10);

            //Array variable for Bind the data to the current page
            self.currentPageData = ko.observableArray([]);

            // Function to fetch data for the current page
            self.fetchData = function () {
                $.ajax({
                    url: self.DataUrl(),
                    method: "GET",
                    dataType: "json",
                    success: function (response) {
                        self.Data(response); // Populate allData array with fetched data
                        self.totalPages(Math.ceil(self.Data().length / self.itemsPerPage())); // Update total pages
                        // by default loading first 10 records and show on the page
                        self.currentPageData(self.Data().slice(self.currentPage() - 1, self.itemsPerPage()));
                    },
                    error: function (error) {
                        console.log("error: ", error);
                    }
                });
            };

            // Calculate total pages based on total items and items per page
            self.totalPages = ko.observable();

            // Function to navigate to the previous page
            self.goToPreviousPage = function () {
                if (self.currentPage() > 1) {
                    self.currentPage(self.currentPage() - 1);
                }
            };

            // Function to navigate to the next page
            self.goToNextPage = function () {
                if (self.currentPage() < self.totalPages()) {
                    self.currentPage(self.currentPage() + 1);
                }
            };

            // Function to navigate to a specific page
            self.goToPage = function (pageNumber) {
                self.currentPage(pageNumber);
            };

            // Watch for changes in currentPage and fetch data accordingly
            self.currentPage.subscribe(function () {
                var startIndex = (self.currentPage() - 1) * self.itemsPerPage();
                var endIndex = startIndex + self.itemsPerPage();
                self.currentPageData(self.Data().slice(startIndex, endIndex));
            });

            // Initially fetch all data
            self.fetchData();
        }

        $(document).ready(function () {
            ko.applyBindings(new AppViewModel());
        });
    </script>



Output:
