AngularJS Custom Directive
Custom directives in AngularJS can extend the functionality of HTML by creating reusable objects or actions. They are a powerful feature with robust DOM transformation, provide reusable UI components, and improve code design. Here is an explanation of how custom directives work in AngularJS:
Basics of Custom Directives
Direction Definition Object (DDO)
A method is defined by a directive definition object (DDO), which specifies how the directive should behave, what parameters or functions it should use, and how it should interact with the DOM.
Directive Types
- Element assignments- Create a new HTML element.
- Attribute directives Change the behavior or appearance of existing features.
- Class directives- Apply characters or strategies to objects based on their learning.
- Comment directives- Restrict directives to HTML text.
Structure of a Custom Directive
Here is a prime example of traditional teaching,
// Example: Custom directive 'myDirective'
app.directive('myDirective', function() {
return {
restrict: 'E', // Restrict usage to elements
template: '<div>{{ message }}</div>', // Inline template
scope: {
message: '@' // One-way binding (string)
},
link: function(scope, element, attrs) {
// Link function: DOM manipulation and behavior
element.on('click', function() {
element.css('background-color', 'yellow');
});
}
};
});
Description of Directory Definition Object (DDO)
restrict-Specifies how the directive can be used. Possible values are:
- ‘E’- element directions (<my-direction></my-direction>).
- ‘a’- attribute directions (<div my-direction></div>).
- ‘c’- class direction (<div class="my-direction"></div>).
- ‘m’- instruction directive (<!-- directive my-directive -->).
template or templateUrl- Defines the appearance/design of the guide. It can be an inline HTML (template) or a URL in an external file (templateUrl).
scope- Defines the isolated scope of the doctrine. This determines the behavior of the binding data of the instruction. The most common options are:
- @- One-way binding (string).
- =- bilateral relation (object).
- &- binding function (words).
‘Link’ function- Each directive is executed once per instance. This allows you to manipulate the DOM, add event listeners, interact with controllers, and perform other directive-specific operations.
Using the Custom Directive
Once defined, you can use the custom directives in your HTML just like any embedded AngularJS directive:
<my-directive message="Hello from directive"></my-directive>
Benefits of Custom Directives
Reusability- Add complex behavior or UI components for reuse in your application.
Separation of concerns- DOM promotes clean code by separating variables and business logic.
Improved readability- Increases readability and maintainability by squeezing complex HTML and JavaScript interfaces into reusable objects.
Application of the model
Form Validation- Create custom validation behavior or error messages.
UI components- Create reusable elements such as modals, tooltips, or sliders.
Data visualization- Use custom charts or graphs.
Event handling- Associate specific behavior with DOM events in a reusable way.
Example-
<!DOCTYPE html>
<html data-ng-app="myApp">
<head>
<meta charset='utf-8'>
<meta http-equiv='X-UA-Compatible' content='IE=edge'>
<title>Page Title</title>
<meta name='viewport' content='width=device-width, initial-scale=1'>
<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet"
integrity="sha384-QWTKZyjpPEjISv5WaRU9OFeRpok6YctnYmDr5pNlyT2bRjXh0JMhjY6hW+ALEwIH" crossorigin="anonymous">
<script src="https://ajax.googleapis.com/ajax/libs/angularjs/1.8.2/angular.min.js"></script>
</head>
<body data-ng-controller ="myController">
<div class="container my-4">
<!-- first way to load the custome file in your custome directive as attribute -->
<div my-directive></div>
<hr>
<!-- other way to load custome file in your custome derective as element -->
<my-directive text-color="blue"></my-directive>
</div>
<script>
angular.module('myApp', [])
.controller('myController', ['$scope', function($scope){
$scope.name = "This is Custom Directive file message";
}])
.directive('myDirective', function(){
return {
// Custom file location with file name
templateUrl: "Custome-file.html",
link: function(scope, element, attrs){
// apply the css on custome file attributes
var textColor = attrs.textColor;
// Applying CSS properties to the element
element.css({
'color': textColor
});
// apply mouseover event on customefile elements
element.on('mouseover', function(){
element.css('background-color', 'yellow');
});
// apply mouseout event on customefile elements
element.on('mouseout', function(){
element.css('background-color', 'transparent');
});
}
};
});
</script>
</body>
</html>Custome-file.html
<div class="row">
<div class="col-12">
<!-- -->
<h3>This is custome file</h3>
<!-- bind the value of $scope.name here -->
<p data-ng-bind="name"></p>
</div>
</div>
Note above files keep in same folder or directive
Output-
Custom directives are key in AngularJS for building modular, maintainable applications with improved functionality and improved code organization. They empower developers to extend the capabilities of HTML and create more transparent, reusable features and actions in their applications.
